Mini Suction Cups
Brand :
MISUMI
Caution
- Please check the content on our website as the PDF does not contain the most up-to-date information.
Product Description
[Features]·A mini pad for adsorbed objects. [Material]·Rubber.
| Type | [ M ] Material | [ H ] Hardness | Heat Resistance Temp. | Electrical Resistance | |
| Round | Square | ||||
| RBTR | RBTS | Nitrile Rubber (Black) | Shore A80 | −20~150°C | 1.0x105Ω |
| SCTR | SCTS | Silicon Rubber (Black) | Shore A60 | −70~200°C | 1.0x105Ω |
Price list
■Volume Discount Rate P.87
| Quantity | 1~29 | 30~49 | 50~99 |
| Rate | Unit Price | 5% | 10% |
More Information
■Features
1. Makes no scratch on devices.
2. Easy replacement by sharing the holder insert part.
3. Devices can be definitely absorbed and attached or removed.
Although up to size and shape of device, the tip of Mini Suction Cup is selectable, holder insertion part has only 2 types to select, and used in common, to provide easy insertion and replacement of this product.
To vacuum, use it while applying air pressure.
To remove, stop the air pressure.
The surface of the absorptive portion of the mini suction cups is treated with satin finish, providing easy device removal.
The material of RBTR - RBTS is NBR (Nitrile Rubber) and can vacuum (convey) with no scratch on devices.
The material of SCTR and SCTS is silicon rubber and excels in chemical, heat, low temperature and weather resistance.
1. Makes no scratch on devices.
2. Easy replacement by sharing the holder insert part.
3. Devices can be definitely absorbed and attached or removed.
Although up to size and shape of device, the tip of Mini Suction Cup is selectable, holder insertion part has only 2 types to select, and used in common, to provide easy insertion and replacement of this product.
To vacuum, use it while applying air pressure.
To remove, stop the air pressure.
The surface of the absorptive portion of the mini suction cups is treated with satin finish, providing easy device removal.
The material of RBTR - RBTS is NBR (Nitrile Rubber) and can vacuum (convey) with no scratch on devices.
The material of SCTR and SCTS is silicon rubber and excels in chemical, heat, low temperature and weather resistance.
