Pin Gauge EP Series
Brand :
EISEN
Caution
Product Description
[Features]
· EISEN PIN GAUGE EP Series is made in Japan
· Used to accurately measure inner diameter starts at 0.05 mm (0.01 mm increment)
· All sizes are available.
· Specification:
- Diameter: 0.05 - 0.19 mm (Tolerance ±1.0 μm, Class1)
- Diameter: 0.20 - 10.00 mm (Tolerance ±0.5 μm, Class 0)
- Diameter: 10.01 - 20.01 mm (Tolerance ±0.5 μm, Class 1)
Remark
- Product is packed inside hexagon case with anti-rust paper.
- Size number is engraved on product which has diameter more than 1 mm
- Actual measured value is engraved on product case only Class 0 items
Hardness: 68 HRC
Material:
Size 0.20 - 0.99 mm made from SKH51
Size 1.00 - 20.01 mm made from SUJ2
[Features]
· EISEN PIN GAUGE EP Series is made in Japan
· Used to accurately measure inner diameter starts at 0.05 mm (0.01 mm increment)
· All sizes are available.
· Specification:
- Diameter: 0.05 - 0.19 mm (Tolerance ±1.0 μm, Class1)
- Diameter: 0.20 - 10.00 mm (Tolerance ±0.5 μm, Class 0)
- Diameter: 10.01 - 20.01 mm (Tolerance ±0.5 μm, Class 1)
Remark
- Product is packed inside hexagon case with anti-rust paper.
- Size number is engraved on product which has diameter more than 1 mm.
- Actual measured value is engraved on product case only Class 0 items.
Hardness: 58 HRC or more
Material:
Size 0.20 - 0.99 mm made from SKH51
Size 1.00 - 20.01 mm made from SUJ2
Maker catalog click
· EISEN PIN GAUGE EP Series is made in Japan
· Used to accurately measure inner diameter starts at 0.05 mm (0.01 mm increment)
· All sizes are available.
· Specification:
- Diameter: 0.05 - 0.19 mm (Tolerance ±1.0 μm, Class1)
- Diameter: 0.20 - 10.00 mm (Tolerance ±0.5 μm, Class 0)
- Diameter: 10.01 - 20.01 mm (Tolerance ±0.5 μm, Class 1)
Remark
- Product is packed inside hexagon case with anti-rust paper.
- Size number is engraved on product which has diameter more than 1 mm.
- Actual measured value is engraved on product case only Class 0 items.
Hardness: 58 HRC or more
Material:
Size 0.20 - 0.99 mm made from SKH51
Size 1.00 - 20.01 mm made from SUJ2
Maker catalog click
