Delta Inverter, VFD-ED Series (Elevator Drive)
Brand :
DELTA
Caution
Product Description
Delta's VFD-ED series AC motor drive designed for elevators are based on years' of experiences in designing AC motor drives, and the experience accumulated since the first Delta elevator AC motor drive VL series launched in 2007. The VFD-ED Series Not only keep safety as first priority but also enhances operation efficiency and riding comfort.
Catalog
Delta Elevator Drive VFD-ED Series Catalog Click here
Applications
Home elevator, cargo elevator, passenger elevator in both residential and commercial buildings
Specifications
- Power rating from 2.2 kW to 75 kW
- Supports both asynchronous and synchronous motors
- Output frequency up to 0 ~ 299 Hz
- 8 programmable digital inputs/ 6 programmable output
- Supports various encoders (ABZ, ABZ+UVW, SIN/COS, SIN/COS+Endat2.1)
- Supports single output contactor operation (SIL2)
- Built-in with CAN/Modbus communication interface
- Built-in 7 segment digit keypad, optional LCD keypad available
- Auto-tuning with the load attached
- Overload capacity up to 200%
- Supports 1-phase 230VAC Uninterrupted Power System(UPS)
- Compact dimensions
