Cap Magnet Square Shape (Type L)

Square shape (type L) of applied magnet that has achieved more powerful magnetic force by combining a ferrite magnet and a yoke (iron) to concentrate the force in the fixed direction. Can be mounted easily with the screw holes in the yoke. The attraction power is 5 to 10 times as powerful as a magnet alone.

[Features]
▪ No demagnetization occurs because the coercive force is high.
▪ It is a sintered magnet (ceramic magnet), excellent in corrosion resistance and suitable for a flat shape but cracked easily.
▪ Applications are expanding from the traditional fields including audio speakers and headphones, to cover automotive motors and generators where the demand for products like this is growing as a result of weight reduction (1/2 to 1/3 compared with a conventional one) made possible by technological innovation.
