E3Z Photoelectric Sensor With Built-in Small Amplifier

Brand :

OMRON

Caution

Product Description

The standard for photoelectric sensors. Produced in volumes of 1 million units per year.
[Features]
· Long-distances: Thru-beam type / 30 m; Retroreflective type / 4 m; Diffuse reflection type / 1 m.
· Easy to adjust the optical axis: Deviation between the optical axis and machine axis is within ±2.5°.
· High stability: Proprietary algorithm that prevents ambient light from affecting performance.

E3Z Photoelectric Sensor with Built-in Amplifier

For detailed product specifications, download the catalog: Click here

E3Z Photoelectric Sensor Catalog Page

E3Z-D Series – Diffuse-reflective Type

Sensing Method	Diffuse-reflective
Detection Distance	100 mm to 1,000 mm (typical)
Light Source	Red LED
Best For	Standard object detection with reflected light

E3Z-R Series – Retro-reflective Type

Sensing Method	Retro-reflective (requires reflector)
Detection Distance	Up to 4 m (with reflector)
Light Source	Red or Infrared LED
Special Feature	Models with MSR (Mirror Surface Rejection)

E3Z-T Series – Through-beam Type

Sensing Method	Through-beam (emitter and receiver)
Detection Distance	Up to 30 m
Light Source	Infrared LED
Best For	High-speed, long-distance, precise detection

E3Z-L Series – Limited Reflective Type

Sensing Method	Limited Reflective
Detection Distance	10 to 100 mm
Light Source	Red LED
Best For	Transparent or micro-object detection

IO-Link Models – Smart Sensor Options

Feature	Supports IO-Link communication
Available Types	Diffuse-reflective, Retro-reflective
Benefit	Real-time monitoring, parameter setting

Common Specifications Across All Types

Output Type	NPN / PNP Open-collector
Operation Mode	Light ON / Dark ON (selectable)
Power Supply Voltage	12 to 24 VDC ±10%
Protection Rating	IP67, IP69K (on select models)
Ambient Temperature	-25°C to +55°C
Response Time	1 ms max.
Housing Material	PBT (Polybutylene Terephthalate)
Connection Types	Cable (0.3m / 0.5m / 2m / 5m), M8 / M12 connector
