Cable Ties With Clamp
Brand :
MISUMI
Caution
Product Description
Cable Ties With Clamp.
This tool come up with plastic clip clamp for grip the strenght metal sheet without drilling holes,
which helpful for simplifying processes, saving time to install the cable tie ( 1 pack per 50 pieces )
[Features]
• Operating temperature: -40~ +105°C
• Material used to produce:
Cable Ties and Clips : Nylon 66 (UL94HB)
Metal Fitting Part : C75S Steel (Chromium-free Surface Plating)
• Color: Black
[Applications]
Suitable for fixing ultra-thick panels where it is difficult to punch holes.
FEATURES Easy to use cable ties with clamp
● Suitable for fixing ultra-thick panels where it is difficult to punch holes.
●Helpful for simplifying processes, saving time and effort.
● Provides a buffering effect while fixing the wiring.
● Suitable for fixing ultra-thick panels where it is difficult to punch holes.
●Helpful for simplifying processes, saving time and effort.
● Provides a buffering effect while fixing the wiring.
· Cable ties are supplied with the product.
Manufacturer: Hellermann Tyton
Manufacturer: Hellermann Tyton
Specification Table
| Part Number | Package Quantity | Color | Banding Location | Banding Direction | Banding Type | Bundling Diameter (φmm) | Banding Size (mm) | Compatible Plate Thickness (mm) | Minimum Ring Tensile Strength (kgf) | |||
| Minimum | Max. | Full Length | Width | Minimum | Max. | |||||||
| RHEC9-50P | 50 pcs | Black | Above Clamp | Parallel with Attaching Clamp | General-Purpose Cable Ties (Serrated Inside) | 5.0 | 45 | 202 | 4.6 | 1.0 | 3.0 | 22.94 |
| RHEC10-50P | Perpendicular to Attaching Clamp | |||||||||||
| RHEC19-50P | Parallel with Attaching Clamp | 3.0 | 6.0 | |||||||||
| RHEC20-50P | Perpendicular to Attaching Clamp | |||||||||||
| RHEC21-50P | Clamp Side | Perpendicular to Attaching Clamp | 1.0 | 3.0 | ||||||||
| ROEC22-50P | Parallel with Attaching Clamp | Wear-Resistant Cable Ties (Serrated Outside) | 200 | |||||||||
| ROEC23-50P | Perpendicular to Attaching Clamp | 3.0 | 6.0 | |||||||||
| ROEC24-50P | Parallel with Attaching Clamp | |||||||||||
Example of Use
