Centronics Connector Cable (With MISUMI Original Connector)
Brand :
MISUMI
Caution
Product Description
Used for connecting personal computer and printer
● A Centronics connector harness with a significantly lowered price thanks to the use of original Misumi parts.
● An EMI countermeasure harness that can be used for connecting control devices, printers, etc.
● By taking advantage of the free alteration / custom number, connection and mark tube printing specification changes can be performed easily.
● Newly added KS / RS cables.
· It cannot be connected with the screw lock model.
· The mark tube has the connector pin number printed on it as standard.
· The shield is connected to the hood.
· Specifying the length of the connector side ground cable is not supported.
· The combination of the Centronics connector and other connectors' combination harness can be handled with the "Web Setting Harness Plus."
Specifications
| Connector Type | Shape Specification Type | Outline Image Drawing | Cable Type | Number of Cores | Specified Length (m) |
| CENT EMI Countermeasure Type Solder Connector Spring Lock Type | P (Male) |  |  | 14 | 0.2 ~ 50 Can be specified by 0.1m increments |
| 24 | |||||
| 36 | |||||
| 50 | |||||
| S (Female for Relay) |  | 14 | |||
| 24 | |||||
| 36 | |||||
| 50 | |||||
| PP (Male / Male) |  | 14 | |||
| 24 | |||||
| 36 | |||||
| 50 | |||||
| SS (Female for Relay/ Female for Relay) |  | 14 | |||
| 24 | |||||
| 36 | |||||
| 50 | |||||
| PS (Male / Female for Relay) | 14 | ||||
| 24 | |||||
 | 36 | ||||
| 50 |
* - is not available.
| Connector Type | Shape Specification Type | Outline Image Drawing | Cable Type | Number of Cores | Specified Length (m) |
| CENT EMI Countermeasure Type Solder Connector Spring Lock Type | PY (Male / Y Terminal) With Pin No. Insertion Mark Tube |  |  | 14 | 0.2 ~ 50 Can be specified by 0.1 m increments |
| 24 | |||||
| 36 | |||||
| 50 | |||||
| SY (Female / Y Terminal) With Pin No. Insertion Mark Tube |  | 14 | |||
| 24 | |||||
| 36 | |||||
| 50 | |||||
| PT (Male / Loose Wires) With Pin No. Insertion Mark Tube |  | 14 | |||
| 24 | |||||
| 36 | |||||
| 50 | |||||
| ST (Female / Loose Wires) With Pin No. Insertion Mark Tube | 14 | ||||
| 24 | |||||
 | 36 | ||||
| 50 |
