- Locating Pins - Straight, Sphere (Press Fit) from MISUMI.
- The sphere head can prevent the mating side from being scratched. Selectable tolerance with each dimension configurable.
- SUS440C or 13Cr stainless has an identification groove at any position on D part.
- When the D dimension is small, a centering hole will cause the sphere section to become small.
- On some combination of dimensions, the center hole may not be available.
- Polishing and centering hole is sometimes not available for SUS304.
Material No. | [ M ]Material | [ S ]Surface Treatment | [ H ]Hardness | Type |
Press Fit | ||||
(1) | SKS3 Equivalent | - | Treated Hardness: 60~63HRC | LPSQA |
(2) | SKS3 Equivalent | Hard Chrome Plating | Treated Hardness: 50~55HRC Plating Hardness: 750HV~ | GLPSQA |
(3) | SKS3 Equivalent | - | - | BLPSQA |
(4) | SUS304 | - | - | SLPSQA |
(5) | SUS304 | Hard Chrome Plating | Plating Hardness: 750HV~ | HLPSQA |
(6) | SUS440C or 13Cr stainless | - | Treated Hardness: 50~55HRC | CLPSQA |
Part Number | - | L | ||||
Type | Tolerance | D | ||||
LPSQA | M | 6 | - | L14.0 |
D | Standard Grade | |||
M | P | G | H | |
m6 | p6 | g6 | h7 | |
1~3 | +0.008 +0.002 | +0.012 +0.006 | -0.002 -0.008 | 0 -0.010 |
4~6 | +0.012 +0.004 | +0.020 +0.012 | -0.004 -0.012 | 0 -0.012 |
8, 10 | +0.015 +0.006 | +0.024 +0.015 | -0.005 -0.014 | 0 -0.015 |
Part Number | L 0.1mm Increment | C | ||
