High Torque Timing Pulleys - 1.5GT / 2GT Type
Brand :
MISUMI
Caution
- Please note that the swaged flange options, NFC, RFC, and LFC, are not reflected in the CAD data.
Product Description
Since it has an arc tooth profile, it has little backlash and it is suitable for positioning applications.
[Material]
· Pulley: Aluminum alloy
· Flange: Aluminum alloy
[Surface treatment]
· Clear anodize
[Related Products]
· Timing belt High Torque Timing Belt,
· Idler Idler with Teeth Center Bearing, Idler with Teeth Both Sides Bearing, Idler - Backside Tensioning Center Bearing, Idler - Backside Tensioning Both Sides Bearing
