Rotary Joints - Elbows
Brand :
MISUMI
Caution
- There are some errors in the CAD and 3D preview for RTCNL4-M5 and RTCNL6-M5, and we are currently working to correct them. Apologies for any inconvenience this may cause.
- Please check the content on our website as the PDF does not contain the most up-to-date information.
Product Description
[Features]·Quick-connect fitting for oscillating parts and rotating piping. ·An elbow type.
More Information
■Features
- Use as handy couplings for connecting tubes to swivel and rotary parts of general pneumatic equipment.
- With ball bearings used at the rotary part, rotary joints offer suitable use for tube connecting to fast-moving swivel and rotary equipment parts.
- Use as handy couplings for connecting tubes to swivel and rotary parts of general pneumatic equipment.
- With ball bearings used at the rotary part, rotary joints offer suitable use for tube connecting to fast-moving swivel and rotary equipment parts.
■ Specifications
*No freezing
| Applicable Fluid | Air |
| Operating Temperature Range* | 0 to 60°C |
| Max. Operating Pressure | 1 Mpa |
| Operating Vacuum Level | -100 kPa |
