Configure

Part number has not been determine

(178 Part Numbers Available)

Configure Remaining Specifications

Part Number Complete

MPBZ5-8

Inner Dia. d Outer Dia. D Overall Length L type CAD Days to Ship

Specification/Dimensions

Inner Dia. d(Ø)
5

6

8

10

12

13

15

16

18

20

25

30

35

40

50

60

80

100
Clear
Outer Dia. D(Ø)
9

10

12

14

18

19

21

22

24

28

30

33

35

38

44

50

62

75

96

120
Clear
Overall Length L(mm)
8

9

10

12

15

16

19

20

25

30

35

40

50

60

70

80

100
Clear
type
- MPBZ
Clear
CAD
- 2D
- 3D
Clear

Days to Ship

All

Same day

3 Day(s) or Less
Clear

Specify Alterations

Oil Free Bushings - Copper Alloy Straight, Standard

Compare This Product

Volume Discount

Brand :

Part Number :

MPBZ5-8

MPBZ5-9

MPBZ5-10

MPBZ5-12

MPBZ5-15

MPBZ6-8

MPBZ6-9

MPBZ6-10

MPBZ6-12

MPBZ6-15

MPBZ6-16

MPBZ6-19

MPBZ6-20

MPBZ8-8

MPBZ8-9

MPBZ8-10

MPBZ8-12

MPBZ8-15

MPBZ8-16

MPBZ8-19

MPBZ5-8

From :

฿ 79.20/Unit
Qty :
Days to Ship :

---
Total Price :

---

Select part number to Order Now/ Add to Cart

CAD Download

Product Description

- Oil Free Bushings - Copper Alloy Straight, Standard type, MPBZ series from MISUMI.
- Copper Alloy Bushings in general use. Straight Shape Type.
- Recommended mating shaft for I.D. of Copper oil-free bushing MPBZ series are d8: General use (High Load), e7: General use (Light Load), f8: High precision use, g6: High precision use (Intermittent operation).
- Use of rotation stopper screws is recommended to affix bushings.
- The Copper oil-free bushing MPBZ series is made of High tensile brass alloy with solid lubricant embedded.

Product TOP

Part Number

Incomplete part number.
Please use left hand selections to complete a part number.

: 30; 60; 90

Part Number
MPBZ5-8
MPBZ5-9
MPBZ5-10
MPBZ5-12
MPBZ5-15
MPBZ6-8
MPBZ6-9
MPBZ6-10
MPBZ6-12
MPBZ6-15
MPBZ6-16
MPBZ6-19
MPBZ6-20
MPBZ8-8
MPBZ8-9
MPBZ8-10
MPBZ8-12
MPBZ8-15
MPBZ8-16
MPBZ8-19
MPBZ8-20
MPBZ8-25
MPBZ10-8
MPBZ10-9
MPBZ10-10
MPBZ10-12
MPBZ10-15
MPBZ10-16
MPBZ10-19
MPBZ10-20
MPBZ10-25
MPBZ10-30
MPBZ12-8SALE
MPBZ12-9
MPBZ12-10
MPBZ12-12
MPBZ12-15
MPBZ12-16
MPBZ12-19
MPBZ12-20
MPBZ12-25
MPBZ12-30
MPBZ12-35SALE
MPBZ13-9
MPBZ13-10
MPBZ13-12
MPBZ13-15
MPBZ13-16
MPBZ13-19
MPBZ13-20
MPBZ13-25SALE
MPBZ13-30SALE
MPBZ13-35
MPBZ15-9
MPBZ15-10
MPBZ15-12
MPBZ15-15
MPBZ15-16
MPBZ15-19
MPBZ15-20
MPBZ15-25
MPBZ15-30
MPBZ15-35SALE
MPBZ15-40
MPBZ16-9SALE
MPBZ16-10
MPBZ16-12
MPBZ16-15
MPBZ16-16
MPBZ16-19
MPBZ16-20
MPBZ16-25
MPBZ16-30
MPBZ16-35
MPBZ16-40
MPBZ18-9SALE
MPBZ18-10
MPBZ18-12SALE
MPBZ18-15SALE
MPBZ18-16SALE
MPBZ18-19
MPBZ18-20
MPBZ18-25
MPBZ18-30
MPBZ18-35
MPBZ18-40
MPBZ20-9SALE
MPBZ20-10
MPBZ20-12
MPBZ20-15

Price	Name	Minimum Order Qty.	Volume Discount	Days to Ship	RoHS	Inner Dia. d (Ø)	Outer Dia. D (Ø)	Overall Length L (mm)
฿ 104.40	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	5	9	8
฿ 248.04	OIL FREE BUSH	1 Piece(s)	Available	3 Day(s)	10	5	9	9
฿ 104.40	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	5	9	10
฿ 104.40	OIL FREE BUSH	1 Piece(s)	Available	3 Day(s)	10	5	9	12
฿ 124.20	OIL FREE BUSHINGS	1 Piece(s)	Available	Same day	10	5	9	15
฿ 93.60	OILFREEBUSH	1 Piece(s)	Available	Same day	10	6	10	8
฿ 225.17	OIL FREE BUSH	1 Piece(s)	Available	3 Day(s)	10	6	10	9
฿ 93.60	OILFREEBUSH	1 Piece(s)	Available	Same day	10	6	10	10
฿ 93.60	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	6	10	12
฿ 104.40	OILFREEBUSH	1 Piece(s)		Same day	10	6	10	15
฿ 138.60	OIL FREE BUSH	1 Piece(s)	Available	3 Day(s)	10	6	10	16
฿ 293.07	OIL FREE BUSH	1 Piece(s)	Available	3 Day(s)	10	6	10	19
฿ 124.20	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	6	10	20
฿ 79.20	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	8	12	8
฿ 181.37	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	8	12	9
฿ 81.00	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	8	12	10
฿ 84.60	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	8	12	12
฿ 86.40	OILFREEBUSH	1 Piece(s)	Available	Same day	10	8	12	15
฿ 127.80	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	8	12	16
฿ 259.12	OIL FREE BUSH	1 Piece(s)	Available	3 Day(s)	10	8	12	19
฿ 110.70	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	8	12	20
฿ 133.20	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	8	12	25
฿ 79.20	OILFREEBUSH	1 Piece(s)	Available	Same day	10	10	14	8
฿ 203.00	OIL FREE BUSH	1 Piece(s)	Available	3 Day(s)	10	10	14	9
฿ 81.00	OILFREEBUSH	1 Piece(s)	Available	Same day	10	10	14	10
฿ 84.60	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	10	14	12
฿ 86.40	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	10	14	15
฿ 111.45	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	10	14	16
฿ 225.17	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	10	14	19
฿ 90.90	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	10	14	20
฿ 119.70	OILFREEBUSH	1 Piece(s)	Available	Same day	10	10	14	25
฿ 136.80	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	10	14	30
฿ 84.60 ฿ 49.43	OIL FREE BUSH	1 Piece(s)		Same day	10	12	18	8
฿ 225.17	OIL FREE BUSH	1 Piece(s)	Available	3 Day(s)	10	12	18	9
฿ 83.70	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	12	18	10
฿ 88.20	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	12	18	12
฿ 94.50	OIL FREE BUSHINGS	1 Piece(s)	Available	Same day	10	12	18	15
฿ 122.08	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	12	18	16
฿ 97.03	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	12	18	19
฿ 97.20	OIL FREE BUSHINGS	1 Piece(s)	Available	Same day	10	12	18	20
฿ 113.40	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	12	18	25
฿ 122.40	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	12	18	30
฿ 154.80 ฿ 67.97	OILFREEBUSH	1 Piece(s)		Same day	10	12	18	35
฿ 270.21	OIL FREE BUSH	1 Piece(s)	Available	3 Day(s)	10	13	19	9
฿ 104.40	OILFREEBUSH	1 Piece(s)	Available	Same day	10	13	19	10
฿ 128.70	OIL FREE BUSH	1 Piece(s)		Same day	10	13	19	12
฿ 121.50	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	13	19	15
฿ 257.04	OIL FREE BUSH	1 Piece(s)	Available	3 Day(s)	10	13	19	16
฿ 326.33	OIL FREE BUSH	1 Piece(s)	Available	3 Day(s)	10	13	19	19
฿ 125.10	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	13	19	20
฿ 161.60 ฿ 64.66	OIL FREE BUSH	1 Piece(s)		Same day	10	13	19	25
฿ 179.32 ฿ 99.94	OIL FREE BUSH	1 Piece(s)		Same day	10	13	19	30
฿ 177.30	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	13	19	35
฿ 293.07	OIL FREE BUSH	1 Piece(s)	Available	3 Day(s)	10	15	21	9
฿ 111.60	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	15	21	10
฿ 117.90	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	15	21	12
฿ 125.10	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	15	21	15
฿ 159.21	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	15	21	16
฿ 326.33	OIL FREE BUSH	1 Piece(s)	Available	3 Day(s)	10	15	21	19
฿ 128.70	OIL FREE BUSHINGS	1 Piece(s)	Available	Same day	10	15	21	20
฿ 134.10	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	15	21	25
฿ 149.40	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	15	21	30
฿ 188.10 ฿ 105.30	OIL FREE BUSH	1 Piece(s)		Same day	10	15	21	35
฿ 201.60	OILFREEBUSH	1 Piece(s)		Same day	10	15	21	40
฿ 293.07 ฿ 154.27	OIL FREE BUSH	1 Piece(s)		Same day	10	16	22	9
฿ 113.40	OILFREEBUSH	1 Piece(s)	Available	Same day	10	16	22	10
฿ 119.70	OILFREEBUSH	1 Piece(s)	Available	Same day	10	16	22	12
฿ 126.00	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	16	22	15
฿ 164.53	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	16	22	16
฿ 326.33	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	16	22	19
฿ 128.70	OIL FREE BUSHINGS	1 Piece(s)	Available	Same day	10	16	22	20
฿ 131.40	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	16	22	25
฿ 156.60	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	16	22	30
฿ 188.10	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	16	22	35
฿ 208.80	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	16	22	40
฿ 394.23 ฿ 209.61	OIL FREE BUSH	1 Piece(s)		Same day	10	18	24	9
฿ 128.70	OIL FREE BUSH	1 Piece(s)	Available	3 Day(s)	10	18	24	10
฿ 128.70 ฿ 66.64	OILFREEBUSH	1 Piece(s)		Same day	10	18	24	12
฿ 133.20 ฿ 83.46	OIL FREE BUSH	1 Piece(s)		Same day	10	18	24	15
฿ 206.98 ฿ 184.17	OIL FREE BUSH	1 Piece(s)		Same day	10	18	24	16
฿ 341.67	OIL FREE BUSH	1 Piece(s)	Available	3 Day(s)	10	18	24	19
฿ 149.40	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	18	24	20
฿ 170.10	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	18	24	25
฿ 174.60	OILFREEBUSH	1 Piece(s)	Available	Same day	10	18	24	30
฿ 356.26	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	18	24	35
฿ 254.22	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	18	24	40
฿ 394.23 ฿ 201.96	OIL FREE BUSH	1 Piece(s)		Same day	10	20	28	9
฿ 135.90	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	20	28	10
฿ 286.65	OIL FREE BUSH	1 Piece(s)		Same day	10	20	28	12
฿ 137.70	OIL FREE BUSH	1 Piece(s)	Available	Same day	10	20	28	15

Basic Information

Type	Straight	Metal Type	High-Tensile Brass Alloy	Max. Allowable PV Value Range(N/mm²•m/s)	1.1~2.0
Max. Allowable PV Value(N/mm²•m/s)	1.65	Max. Allowable Surface Pressure P(N/mm²)	29	Maximum Allowable Velocity(m/s)	0.5
Mounting Hole Fits	H7	Operating Temperature Range(°C)	-40::150
