Product DetailSpecification/Dimensions
-
Nominal
-
Pitch, Number of Threads(mm)
-
Number of Chamfered Threads
-
L(mm)
-
Precision
-
Link Diameter(mm)
-
No. of Grooves
- 3
- 4
-
Thread Length
-
External center
- NO
- YES
-
type
- LT-OTT
Days to Ship
-
- All
- 5 Day(s) or Less
Specify Alterations
Tungsten Carbide Straight Flutes Tap with Long Shank_LT-OTT
Copy Part Number URL to Clipboard
The part number URL has been copied into your clipboard.
-
- From :
- ฿ 4,697.00/Unit
-
- Qty :
-
-
- Days to Ship :
- ---
-
- Total Price :
- ---
Select part number to Order Now/ Add to Cart
Similar Products
Product DetailProduct Description
Ideal for tapping large amounts of ordinary cast iron, high-rigidity cast iron, thermosetting resin, brass cast iron, etc., using a high-precision automatic machine.
| Part Number | Price | Name | Minimum Order Qty. | Volume Discount | Days to Ship | Nominal | Pitch, Number of Threads (mm) | Number of Chamfered Threads | L (mm) | Precision | Link Diameter (mm) | No. of Grooves | Thread Length | External center | Protrusion | Tool No. |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
฿ 4,697.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M3 | 0.5 | 1.5P | 100 | OH3 | 4 | 3 | 18 | YES | - | 22917 | ||
฿ 4,862.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M4 | 0.7 | 1.5P | 100 | OH3 | 5 | 3 | 20 | YES | - | 22921 | ||
฿ 5,057.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M5 | 0.8 | 1.5P | 100 | OH3 | 5.5 | 3 | 22 | YES | - | 22925 | ||
฿ 5,445.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M6 | 1 | 1.5P | 100 | OH3 | 6 | 3 | 24 | NO | - | 22929 | ||
฿ 6,706.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M8 | 1 | 1.5P | 150 | OH3 | 6.2 | 4 | 22 | NO | Available | 22937 | ||
฿ 8,093.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M10 | 1 | 1.5P | 150 | OH3 | 7 | 4 | 24 | NO | - | 22949 | ||
฿ 9,601.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M12 | 1 | 1.5P | 150 | OH3 | 8.5 | 4 | 29 | NO | Available | 22965 | ||
฿ 6,706.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M8 | 1.25 | 1.5P | 150 | OH4 | 6.2 | 4 | 22 | NO | Available | 22933 | ||
฿ 8,093.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M10 | 1.5 | 1.5P | 150 | OH4 | 7 | 4 | 24 | NO | - | 22941 | ||
฿ 8,093.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M10 | 1.25 | 1.5P | 150 | OH4 | 7 | 4 | 24 | NO | - | 22945 | ||
฿ 9,601.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M12 | 1.5 | 1.5P | 150 | OH4 | 8.5 | 4 | 29 | NO | Available | 22957 | ||
฿ 9,601.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M12 | 1.25 | 1.5P | 150 | OH4 | 8.5 | 4 | 29 | NO | Available | 22961 | ||
฿ 9,601.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M12 | 1.75 | 1.5P | 150 | OH4 | 8.5 | 4 | 29 | NO | - | 22953 | ||
฿ 9,541.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M14 | 1.5 | 1.5P | 150 | OH4 | 10.5 | 4 | 22 | NO | Available | 22973 | ||
฿ 9,541.00 | CARBIDE TAP | 1 Piece(s) | 5 Day(s) | M14 | 2 | 1.5P | 150 | OH4 | 10.5 | 4 | 29 | NO | Available | 22969 | ||
฿ 11,291.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M16 | 1.5 | 1.5P | 150 | OH4 | 12.5 | 4 | 29 | NO | - | 22981 | ||
฿ 13,284.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M18 | 1.5 | 1.5P | 150 | OH4 | 14 | 4 | 29 | NO | - | 22989 | ||
฿ 15,338.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M20 | 1.5 | 1.5P | 150 | OH4 | 15 | 4 | 29 | NO | - | 22997 | ||
฿ 11,291.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M16 | 2 | 1.5P | 150 | OH5 | 12.5 | 4 | 29 | NO | - | 22977 | ||
฿ 13,284.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M18 | 2.5 | 1.5P | 150 | OH5 | 14 | 4 | 35 | NO | - | 22985 | ||
฿ 15,338.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M20 | 2.5 | 1.5P | 150 | OH5 | 15 | 4 | 35 | NO | - | 22993 | ||
฿ 4,697.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M3 | 0.5 | 3P | 100 | OH3 | 4 | 3 | 18 | YES | - | 22916 | ||
฿ 4,862.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M4 | 0.7 | 3P | 100 | OH3 | 5 | 3 | 20 | YES | - | 22920 | ||
฿ 5,057.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M5 | 0.8 | 3P | 100 | OH3 | 5.5 | 3 | 22 | YES | - | 22924 | ||
฿ 5,445.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M6 | 1 | 3P | 100 | OH3 | 6 | 3 | 24 | NO | - | 22928 | ||
฿ 6,706.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M8 | 1 | 3P | 150 | OH3 | 6.2 | 4 | 22 | NO | Available | 22936 | ||
฿ 8,093.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M10 | 1 | 3P | 150 | OH3 | 7 | 4 | 24 | NO | - | 22948 | ||
฿ 9,601.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M12 | 1 | 3P | 150 | OH3 | 8.5 | 4 | 29 | NO | Available | 22964 | ||
฿ 6,706.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M8 | 1.25 | 3P | 150 | OH4 | 6.2 | 4 | 22 | NO | - | 22932 | ||
฿ 8,093.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M10 | 1.5 | 3P | 150 | OH4 | 7 | 4 | 24 | NO | - | 22940 | ||
฿ 8,093.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M10 | 1.25 | 3P | 150 | OH4 | 7 | 4 | 24 | NO | - | 22944 | ||
฿ 9,601.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M12 | 1.5 | 3P | 150 | OH4 | 8.5 | 4 | 29 | NO | - | 22956 | ||
฿ 9,601.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M12 | 1.25 | 3P | 150 | OH4 | 8.5 | 4 | 29 | NO | Available | 22960 | ||
฿ 9,601.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M12 | 1.75 | 3P | 150 | OH4 | 8.5 | 4 | 29 | NO | - | 22952 | ||
฿ 9,541.00 | CARBIDE TAP | 1 Piece(s) | 5 Day(s) | M14 | 1.5 | 3P | 150 | OH4 | 10.5 | 4 | 22 | NO | Available | 22972 | ||
฿ 9,541.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M14 | 2 | 3P | 150 | OH4 | 10.5 | 4 | 29 | NO | Available | 22968 | ||
฿ 11,291.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M16 | 1.5 | 3P | 150 | OH4 | 12.5 | 4 | 29 | NO | - | 22980 | ||
฿ 13,284.00 | CARBIDE TAP | 1 Piece(s) | 5 Day(s) | M18 | 1.5 | 3P | 150 | OH4 | 14 | 4 | 29 | NO | - | 22988 | ||
฿ 15,338.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M20 | 1.5 | 3P | 150 | OH4 | 15 | 4 | 29 | NO | - | 22996 | ||
฿ 11,291.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M16 | 2 | 3P | 150 | OH5 | 12.5 | 4 | 29 | NO | Available | 22976 | ||
฿ 13,284.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M18 | 2.5 | 3P | 150 | OH5 | 14 | 4 | 35 | NO | - | 22984 | ||
฿ 15,338.00 | OSG TAP | 1 Piece(s) | 5 Day(s) | M20 | 2.5 | 3P | 150 | OH5 | 15 | 4 | 35 | NO | - | 22992 |
Loading...
Basic Information
| Thread Types | Meter | Tool Material Type | Carbide | Work Material | Cast Iron (FC) / Ductile Cast Iron (FCD) / Brass (Bs) / Brass Cast Iron (BsC) / Bronze (PB) / Cast Aluminum Alloy (AC, ADC) / Cast Magnesium Alloy (MC) / Zinc Alloy Castings (ZDC) / Thermosetting Plastic (Bakelite, Phenol etc.) |
|---|---|---|---|---|---|
| Tap Model | Hand Tap | Bore Model | For Through Holes / For Blind Holes | Coating Presence | None |
| Coating Type | Non-Coated |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
